2019 MSI 3000 HP Double Pumper Trailer

No longer available

2019 MSI 3000 HP Double Pumper Trailer

Financing Available
Apply for credit

Available quantity: 1

Grande Prairie, Canada

Description

www.VIDAEQ.com

2019 3000 HP Twin Quintuplex Pump Trailer


This double pumper package is in great condition!


👉 Viewing this on Machinio? Then follow this link to view the full Equipment Listing https://www.vidaeq.com/listings/5085377-used-2019-msi-3000-hp-double-pumper-trailer


This 3000 HP pumper package has been well cared for and is field ready! Contact Us today to setup your inspection.


Highlight Features

● Tier 4 Engines

● True Twin Pumper

● Low Engine Hours

● Highest Compact Quints Available with Required Horsepower



Benefits Of This Pumper Vs. Frac Units (Coil Tubing)


Double Pumper

  • Takes 2 operators to run per shift
  • 1 Certified Driver
  • Overhead cost for 1 unit per job
  • Small Footprint, 1 unit
  • Ability to have smooth and quick rate transfer of 100 L/min to 1.8 cubes/min, at 69 MPA
  • True twin aspect provides high degree of redundancy for backup on unforeseen failures


Twin and Frac Pump

  • Takes 3 or more operators to run per shift
  • 2 or more Certified Drivers
  • Overhead cost for 2 or more per job
  • Medium Footprint, 2 units
  • Rate transfer requires more time and constant switching between units
  • If a breakdown occurs on the current Twin, Frac Pump can’t maintain the lower rates.


Benefits Of This Pumper Vs. Frac Units (Pumpdown)


Double Pumper

  • Takes 2 operators to run per shift
  • 1 Certified Driver
  • Overhead cost for 1 unit per job
  • Small Footprint, 1 unit
  • Smooth and quick rate transfer
  • For full redundancy, this unit requires one Frac pump


2 Frac Pumpers

  • Takes 3 or more operators to run per shift
  • 2 or more Certified Drivers
  • Overhead cost for 2 or more per job
  • Medium Footprint, 2 units
  • Larger rate jumps result in transfers not being smooth or regulated
  • For full redundancy, this spec requires 3 Frac Pumps


This package is a trailer mounted twin pumping unit designed to deliver treatment fluids to the wellbore in pump down, coil tubing, acidizing applications. The is a simple to operate, trailer mounted, cost-effective pumping unit capable of servicing the intermediate and deep well-bore market.

The trailer is configured to carry 2-inch, Fig. 1502 treating iron, the maximum allowable working pressure (MAWP) of the unit is 103.4 MPa (15,000 PSI).

The unit is mounted on a custom built, 24-wheeler, axle, oilfield trailer chassis, powered by two Cummins QST30 engines. The unit is monitored and controlled from the temperature-controlled operator cabin located rearward of the unit, providing a vantage point to oversee the pumps and treatment operations. The cab has a deck allowing direct access to the displacement tanks.

All equipment controls and the data monitoring package are in the operator cabin. Control panel configuration, layout, and operator ergonomics are all considered in this design. The operator interface is logical and straightforward, operation is intuitive.


General Specifications


Trailer:

Chassis - Center rail, skeletal frame of fabricated T-1 steel Designed for used with tridem tractor

Capacity - 90,000 lbs

Gooseneck - 170 inch gooseneck length,18 inch kingpin setback, 51 inch laden kingpin height

Suspension - Aspen 40 ton poly bushed 24 wheel air ride walking beam suspension. Air scale gauges installed in control box. Dual height control valve installed side by side. Flatten U Bolt system on each axle.


Engines:

Type - 30 L - Two Cummins QST30 Tier IV, V12, 4-cycle Diesel

Rated Power - 1,500 bhp per engine at 1,900 rpm, Tier IV emissions compliant

Radiator - Horizontal 'Jumbotron' dual core jacket water & charge air, transmission oil cooler, hydraulic drive fans, fan guards


Transmission:

Type - Two Cat TH48-E70

Maximum Input Power - 1500 BHP

Maximum Input Speed - 2,100 rpm

Maximum Input Torque - 4,422 ft. lb.

Gears - 7 speed


Quintuplex Pumps:

Type - Two MSI Quintuplex plunger pumps

Maximum Input Power - 1,300 HP each

Rod Load - 106,029 lb.

Stroke Length - 6 inch

Gear Ratio - 4.61:1

Plunger Diameter - 3 inch



To view Full Specifications please open the PDF in the DOCUMENTS section.



Please contact us for further details.


Thank you



Subject to prior sale and/or other disposition.

All Items to be quoted in US currency. All prices and availability are subject to change without notice and are subject to applicable sales tax. Title to all goods listed remain with the seller until the purchase price is fully paid. Equipment is purchased as is, where is, without warranty unless otherwise specified. Use hours are estimate hours as of the date of this posting and are not guaranteed. Equipment pictured may contain attachments and/or accessories not priced in this offer. Sale subject to terms and conditions on final bill of sale.



Contact:

Brandon Martinez

bmartinez@vidabem.us

+1 415 686 8796

www.vidaeq.com



Specifications

ManufacturerMSI
ModelDouble Pumper
Year2019
ConditionUsed
Stock Number00451
Engines1500 HP Cummins QSK 30
Fluid Ends15000 PSI - MSI - 3" Quintuplex
Power Ends1300 HP MSI
TransmissionsCat TH-48
Fuel TypeDiesel
Charge PumpsMission Magnum 6x5x11
Engine HoursApproximately 4400
Pump HoursApproximately 1400
