2014 G TECH Mobile Centrifuge Trailer

2014 G TECH Mobile Centrifuge Trailer

Contact us for price

Financing Available
Apply for credit

Location:Texas

Available quantity:1

orCall +18009572391

Description

www.VIDAEQ.com


2014 G TECH Mobile Centrifuge Trailer


This Mobile Centrifuge Trailer is in great shape. With onboard power all you need to do is to plug in your feed and discharge hose. 2-3 Hour Set up time, no crane required. The solids discard auger will rotate 90 degrees and can be ready to discard solids within minutes of being set up.


The Brochure for this unit is included in the DOCUMENTS section below.


FEATURES INCLUDE:

-DOT Approved Trailer (52' Double Axle)

-Self-Contained w/On Board Secondary Containment

-On Board Pre-Screening/Filtration

-A/C Control Cabin

-HMI Automation Software w/CPU and Screen Monitor

-(2) 1656 G Tech Decanter Centrifuges

-(2) Feed Pumps CFS-200/SM50 Lobe Pump Positive Displacement

-(1) Discharge Pump, CFS-280/SM68 Lobe Pump Positive Displacement

-Agitator Tank w/5HP Electrical Motor

-(3) Micro Motion Flow Meters to Measure Flow, Mud Weight and Temperature

-On Board Power (3 phase, 60Hz, 480v & 120v)

-(3) Built In Tool Boxes

-250kw Gentec Generator

-Self Contained 500 GAL Diesel Tank

-Pressure Washer

-Communication and Remote Access Capability Via Cellular


PERFORMANCE SPECIFICATIONS:

Normal Bowl Centrifuge Acceleration: 2,140 G

Normal Bowl Operating Speed: 3,053 RPM

Normal Conveyor Operating Speed: 2,995 RPM

Max. Bowl Centrifuge Acceleration: 3,140 G

Max. Bowl Operating Speed: 3,700 RPM

Max Effluent Temperature: 212 Degrees F


GEARBOX

The decanter is fitted with a 3025 lbf.ft and the following specification:

Max Output Torque: 3025 lbf.ft

Max Input Torque (Trip Torque): 673 lbf.in

Gearbox Ratio: 53:1


SAFETY SWITCHES

Vibration Switch: Metrix VibrAlert - 5550-111-011

Enclosure Rating: cUL Explosion Proof, Class I, Div 1, Groups C & D

Hopper Switch: NEMA 02ATEX1090X

Enclosure Rating: Ex ia IIC T6, EN 60947-5-6

GS-Coupling Switch: Square D Limit Switch - 9007CR53E

Enclosure Rating: NEMA 1/2/4/6/6P/7/9/12/13


WEIGHTS

1656 Decanter Weight: 4,400 LB

Rotating Assembly Weight: 2,730 LB

Solids End Assembly Weight: 210 LB

Liquid End Assembly Weight: 290 LB

Conveyor Assembly Weight: 670 LB

Bowl Assembly Weight: 360 LB

GB-53 Gearbox Weight (dry): 220 LB

Hopper an Cover Weight: 570 LB



Please contact us for further detail.


Thank you!


Subject to prior sale and/or other disposition.

All Items to be quoted in US currency. All prices and availability are subject to change without notice and are subject to applicable sales tax. Title to all goods listed remain with the seller until the purchase price is fully paid. Equipment is purchased as is, where is, without warranty unless otherwise specified. Use hours are estimate hours as of the date of this posting and are not guaranteed. Equipment pictured may contain attachments and/or accessories not priced in this offer. Sale subject to terms and conditions on final bill of sale.


Contact:

Jose Lozano

jlozano@vidabem.us

661 303 3190

www.vidabem.us


Specifications

ManufacturerG TECH
ModelMobile Centrifuge Trailer
Year2014
ConditionRefurbished
Stock Number00308
Normal Bowl Centrifuge Acceleration2,140 G
Normal Bowl Operating Speed3,053 RPM
Normal Conveyor Operating Speed2,995 RPM
Max. Bowl Centrifuge Acceleration3,140 G
Max. Bowl Operating Speed3,700 RPM
Max Effluent Temperature212 Degrees F
Max Output Torque3025 lbf.ft
Gearbox Ratio53:1
